MTConnectDevices

Definition: root entity of an MTConnectDevices Response Documentresponse document published by an MTConnect Agent in response to a probe request. that contains the Device Information Modelinformation model that describes the physical and logical configuration for a piece of equipment and the data that may be reported by that equipment. of one or more Device entities.

MTConnectDevices

Note: Additional properties of MTConnectDevices MAY be defined for schema and namespace declaration. See Section Schema and Namespace Declaration Information for an XML example.

Version Info

Introduced	Deprecated	Updated
1.0

Relations

Name	Type	Int	Dep	Multiplicity
`hasHeader`	`Header`	1.0		1
`hasDevice`	`Device`	1.0		1..*
~~`hasAssetCount`~~	`AssetCount`	1.2	1.4	0..*

Constraints

Error Message OCL Expression

Error Message	OCL Expression
All `id` and `name` properties MUST be unique.	Components::Component::allInstances()->forAll(comp1, comp2 \| comp1 <> comp2 implies comp1.id <> comp2.id and comp1.name <> comp2.name) and DataItems::DataItem::allInstances()->forAll(di1, di2 \| di1 <> di2 implies di1.id <> di2.id and di1.name <> di2.name) and Components::Devices::Device::allInstances()->forAll(d1, d2 \| d1 <> d2 implies d1.id <> d2.id and d1.name <> d2.name) and Compositions::Composition::allInstances()->forAll(compn1, compn2 \| compn1 <> compn2 implies compn1.id <> compn2.id and compn1.name <> compn2.name)

All id and name properties MUST be unique.

Components::Component::allInstances()->forAll(comp1, comp2 | comp1 <> comp2 implies comp1.id <> comp2.id and comp1.name <> comp2.name)  and
DataItems::DataItem::allInstances()->forAll(di1, di2 | di1 <> di2 implies di1.id <> di2.id and di1.name <> di2.name) and
Components::Devices::Device::allInstances()->forAll(d1, d2 | d1 <> d2 implies d1.id <> d2.id and d1.name <> d2.name) and
Compositions::Composition::allInstances()->forAll(compn1, compn2 | compn1 <> compn2 implies compn1.id <> compn2.id and compn1.name <> compn2.name)
